The crane has a reach of 20.5' including the 3.5' hydraulic extension. C 6,3 lifts 970lbs at full reach and an impressive 3000lbs near the king post. The hydraulic hoses are well protected inside the lift arm and solid steel pipes are used for the extension.
- Deer Horn control valve
- 42'' grapple
- Weight: 1390 lbs
- Slewing torque: 8.8 kNm
- Boom rotation: 360 degrees
- Dual cylinder rack and pinion turnhouse
- Max reach: 20.5'
- Required flow: 5-15 GPM
- Working pressure: 2540 psi
Add telescopic outriggers!
- Mount it on a road trailer or directly to a tractor 3 point hitch (trailer prep required)
- Can be mounted sperately from crane and controlled from the same valve
Add a 9 ton forestry trailer!
- 4 sets of posts
- Adjustable rear extension to allow loading of long logs as well as shortening the trailer for tight areas.
- 440/60-15.5 12 ply forestry tires with reinforced rims
- 48 degree left/right frame steering with cylinder on drawbar
CALL OR EMAIL FOR BEST PRICING!
